Data/Link ID and Cable-Check™ Patch Cable tester and connection identifier. 1576
Function
This handy unit is a multi-purpose continuity
tester and network identifier.
- Continuity tester for UTP, STP and flat satin
cables with RJ45 terminations. Tests both data
and telephone connection schemes including
patch cords and installed cables to identify
- Good connections
- Opens
- Shorts
- Cross-connections
- Identifies data and link transmission speeds
with real time detection:
- Detects the following:
- PC (NIC) and HUB data transmissions
- PC (NIC) and HUB NLP or FLP link pulse
Features and Benefits
- cross-over telephone connections
- Multi-purpose tester at an affordable price
- Two scan speeds: slow or fast
- 9-volt battery included
- Low battery detection on LAN ID tester
- Two (2) RJ45 shielded patch cords included
- Contained in a durable nylon carrying case w/belt loop
Specifications
- Weight 12 oz. (343 g.)
- Dimensions: Main Unit 5.5" L x 2.54" W x 1.61" D (140 mm x 64.5 mm x 41 mm)Remote unit 2.93" L x 1.13" W x .86" D (74.4 mm x 28.7 mm x 21.9 mm)
- Output (Main unit) 9Vdc nominal at 10 mA max.
- Connection type RJ45 UTP or STP modular plug
- Battery 9Vdc NEDA 1604, JIS 006P, IEC 6LR61
- Battery life 15 hours, continuous use
- Max. length:
- Cable mapper 1,650’ (500 m)
- Online PC/Hub 150’ (46 m)*
- Online PC/Hub 450’ (137 m)†
* When testing both sides at HUB & PC
† When testing only at one end near HUB or PC (NIC)
|
